The Cyrix-Li-Charge will connect a battery charger with 3 seconds delay:

• If the Charge Disconnect output of the VE.Bus BMS is high, and
• If it senses 13,7V (resp. 27,4V or 54,8V) or more on its battery charger connection terminal, and
• If it senses 2V or more on its battery terminal (the Cyrix will remain open, if not connect to the battery).

The Cyrix-Li-Charge will disengage immediately whenever its control output becomes free floating, signalling cell over voltage or cell over temperature.

Models

Cyrix-Li-Charge (120A) is available in 12/24V-120A and 24/48V-120A models.
